Acoustic Insulation Movable Partition Wall Customizable Size

  • 1
  • 2

Brand Name : Glawall

Model Number : 100mm ultrahigh style

Certification : SGS, ISO 9001,UL, CE

Place of Origin : China

MOQ : 10 square meters

Price : US$80.00 10 - 99 square meters

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Supply Ability : 3000 square maters per month

Delivery Time : 2-3 weeks

Packaging Details : wooden package

Material : Aluminum frame+glass panel

Transparency : Clear

Customizable : size, accessories

Competitive price : yes

Panel Thickness : 60mm, 100mm

glass type : strong tempered glass

Frame Material : Aluminum

Advantage : Competitive price, good service, high professional, quality guarantee

Contact Now

Acoustic Insulation Movable Partition Wall Customizable Size


Movable Partition Wall Thickness Guide
The thickness of a movable partition wall affects its stability, acoustics, weight, and flexibility. Below is a detailed breakdown of standard and specialized thickness options for different applications.


1. Standard Thickness Ranges

Partition Type Typical Thickness Best For
Basic Office Partitions 50–100 mm (2–4 inches) Open offices, temporary dividers
Glass Partitions 25–40 mm (1–1.5 inches) Modern offices, conference rooms
Acoustic Partitions 75–150 mm (3–6 inches) Meeting rooms, hotels, auditoriums
Extra-Strong Partitions 100–200 mm (4–8 inches) High-security areas, heavy-duty use


Acoustic Insulation Movable Partition Wall Customizable Size



2. Thickness by Material


A. Glass Partitions Single-glazed 25–40 mm (minimal soundproofing)
Double-glazed 50–80 mm (better insulation, STC 40-50)
Laminated security glass Up to 100 mm (impact-resistant)
B. Solid Panel Partitions Aluminum honeycomb core 50–100 mm (lightweight but strong)
Gypsum/mineral wool core 75–150 mm (best for soundproofing, STC 50+)
Solid wood/composite 60–120 mm (luxury finish, mid-range acoustics)
C. Folding/Sliding Partitions Ultra-thin (space-saving) 35–60 mm
Standard (office use) 60–100 mm
Heavy-duty (event halls) 100–200 mm
3. How Thickness Affects Performance Factor Thin (25–60 mm) Thick (75–200 mm)
Soundproofing Low (STC 30-40) High (STC 45-60+)
Weight Light (easy to move) Heavy (needs strong tracks)
Durability Moderate Very strong
Space Efficiency Saves space Takes up more room
Cost Lower Higher
4. Special Cases for Extra Thickness Recording studios 150–200 mm (STC 60+)
Hospital partitions 100–150 mm (hygienic, soundproof)
Ballroom dividers 120–200 mm (high stability for tall walls)
5. Choosing the Right Thickness For offices 50–100 mm (balance of space & acoustics)
For hotels/conference rooms 75–150 mm (better sound control)
For industrial use 100–200 mm (durability & insulation)


Acoustic Insulation Movable Partition Wall Customizable Size


Conclusion
Thicker walls offer better soundproofing and strength, while thinner ones are lightweight and space-saving. The best choice depends on budget, acoustic needs, and structural support.

Need help selecting the right thickness? Share your project details for tailored advice!
